Overspeed Governors

LK120 Bidirectional

Small, super fast.

Triangolo verde

Overspeed governor LK120 Bidirectional

Bidirectional overspeed governor approved by TÜV SUD according to Directive 2014/33/UE and standards EN81-20/50.

Also available with test groove, remote control, rope safety guard, protection cover, device for protection of uncontrolled car movement and anti-creeping assembled on the top of the governor inside the structure.

Triangolo Rosso
LK120 Bidirectional
Pulley Type Pulley Ø 120 mm with hardened groove Bidirectional for rope diameter 6-6.5 mm in derogation
Nominal Speed Up to 2,00 m/s
Tripping Speed From 0,20 m/s up to 2,30 m/s
Hardened groove
Test groove
Certifications EN81-20/50, 2014/33/EU, Gost TP TC 011/2011
Optional
Rope safety guard
Protection cover
Remote control
(IP 50)
Incremental encoder
UCM
Guide rail fixing plate

🔽 : down tripping
🔽🔼 : up and down tripping
